INCH-POUND
MIL-PRF-1/49F
2 November 2007
SUPERSEDING
MIL-E-1/49E
27 April 1972
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, RECEIVING
TYPE 6AS7G
Inactive for new design
after 21 July 1997
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described
herein shall consist of this specification sheet and MIL-PRF-1.
High current, low Mu, double triode.
DESCRIPTION:
Outline
---
4-9.
Base
---
B8-11.
Envelope ---
ST16.
Cathode ---
Coated unipotential.
Base connections:
Pin No. ---
1 2 3 4 5 6 7
8
Element ---
2g 2a 2k 1g 1a 1k h
h
ABSOLUTE RATINGS:
Parameter:
Ef
Eb
Ec
Ib/p
Pp/p
Ehk
Rk/k
TE
Alt
Unit:
V
V dc
V dc
mA dc
W
v
Ohms
°C
ft
Maximum:
6.9
275
---
125
14.0
330
---
200
10,000
Minimum:
5.7
---
---
---
---
---
---
---
---
Test conditions:
6.3
135
0
---
---
---
250
---
---
GENERAL:
First article inspection: Required.
AMSC N/A
FSC 5960
