MIL-PRF-1/480E
Dimensions in inches with metric
equivalents (mm) in parentheses
Ltr
Minimum
Maximum
Conformance inspection, part 2
A
18.000 (457.20)
18.500 (469.90)
B
5.156 (130.96)
5.344 (135.74)
C
3.750 (95.25)
4.250 (107.95)
D
7.000 (177.80)
7.500 (190.50)
F
10.750 (273.05)
11.250 (285.75)
G
2.937 (74.60)
3.062 (77.77)
Conformance inspection, part 3
(periodic check)
BULB: J42M
BASE: B12-37
Reference dimensions (see note c)
E
10.000 (254.00)
H
0.125
(3.18) MAX
NOTES:
1. M-N connected together internally.
2. L and M-N shall be connected together to a common ground.
3. Reference dimensions are for information only and are not required
for inspection purposes.
FIGURE 1. Outline drawing of electron tube types 5SP1A, 5SP7A and 5SP11A - Continued.
Referenced documents. In addition to MIL-PRF-1, this document references the following:
MIL-STD-1311
Marginal notations are not used in this revision to identify changes with respect to the previous issue due to the extent of the
changes.
Custodians:
Preparing activity:
Army - CR
DLA - CC
Navy - EC
Air Force - 85
(Project 5960-2009-010)
Review activities:
Navy - AS, CG, MC, OS
Air Force - 99
