MIL-PRF-1/1634E
Dimensions
Dimensions
Subject
Inches
Millimeters
Notes
Subject
Inches
Millimeters
Notes
Min
Max
Min
Max
Min
Max
Min
Max
E
0.710
0.790
18.03
20.07
Conformance inspection, part 2
A
2.324
2.464
59.03
62.59
F
----
1.406
----
35.71
C
1.810
1.910
45.97
48.51
G
0.187
----
4.75
----
Conformance inspection, part 3
H
Base: B8-236
1
B
1.610
1.640
40.89
41.66
J
0.559
0.573
14.20
14.55
D
0.750
0.810
19.05
20.57
K
0.240
----
6.10
----
NOTES:
1.
Pin alignment shall be checked by means of gauge GB8-3. Dimensions of control-grid contact shall be inspected by
means of gauges specified on drawing 246-JAN (see note 19) and shall be conformance inspection, part 2.
2.
Alignment of anode, screen-grid, and control-grid contact surfaces shall be determined by means of gauges specified
on drawing 168-JAN (see note 19). Conformance inspection, part 2, shall apply.
3.
Air-system socket shall be as specified on drawing 246-JAN (see note 19), EIMAC SK-600, or equal.
4.
Location of guide lug of control-grid contact shall be referenced by a notch or arrow on the anode radiator in position
shown.
5.
Anode clamping shall be confined to anode radiator.
6.
Top cap outline optional provided it meets requirements of dimensions J and K.
FIGURE 1. Outline drawing of electron tube type 8321, 8321A, and 8322.
2
