INCH-POUND
MIL-PRF-1/1622B(USAF)
20 November 1998
SUPERSEDING
MIL-E-1/1622A(USAF)
27 February 1974
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, KLYSTRON
TYPE 7829A
This specification is approved for use by the Department of the Air Force and is
available for use by all Departments and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION:
Reflex, integral cavity, 11.0 GHz, adjustable frequency, 60 mW, waveguide output, convection air cooled.
ABSOLUTE RATINGS:
Alt.
Parameter:
Ef
Ers
Er
Tbody
°C
ft
Unit:
V
V dc
V dc
Maximum:
7.0
350
-500
200
10,000
Minimum:
5.7
----
1/
----
----
PHYSICAL CHARACTERISTICS:
See figure 1.
Dimensions:
Any.
Mounting position:
Mates with UG-39/U and UG-40/U.
Output flange:
Unipotential.
Cathode:
TEST CONDITONS:
Parameter:
Ef
Ers
Er
F
Unit:
V
V dc
V dc
MHz
300 ± 3
11,000 ± 5
6.3
-200 to 400
4/
See footnotes at end of table I.
___________________________________________________________________________________
GENERAL:
Qualification - Required.
AMSC N/A
1 of 5
FSC 5960
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
