INCH-POUND
MIL-PRF-1/1617D
22 August 2014
SUPERSEDING
MIL-PRF-1/1617C
30 January 1998
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, RECEIVING
TYPE 5847A
Inactive for new design
after 29 January 2008.
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION: Pentode, miniature, high gain.
Outline
---
6-1 (EIA)
Base
---
E9-1
Envelope ---
T6-1/2
Cathode
---
Coated unipotential
Base connections:
Pin No.
1
2
3
4
5
6
7
8
9
Element
g1
nc
h,
k,
nc
a
nc
g2
h
lower int
g3 upper
sd
int sd
ABSOLUTE RATINGS: F1= 150 MHz
Parameter:
Ef
Eb
Ec1
Ec2
Rk
lk
Pp
Pg2
Ehk
TE
Alt
°C
Unit:
V
V dc
V dc
V dc
ohms
mA dc
W
W
V
ft
Maximum:
6.9
200
---
165
---
40
3.3
0.85
100
155
1/
---
Minimum:
5.7
---
---
---
---
---
---
---
---
---
Test conditions:
6.3
150
0
150
110
---
---
---
---
---
---
See footnotes at end of table I.
GENERAL:
Qualification: Not required. 2/
This specification sheet uses accept on zero defect sampling in accordance with MIL-PRF-1, table III.
AMSC N/A
FSC 5960
