MIL-PRF-1/1612C
Dimensions
Ltr
Inches
Millimeters
Min
Max
Min
Max
A
3.370
3.625
85.60
92.07
B
---
1.340
---
35.56
D
1.965 DIA
2.040 DIA
49.91 DIA
51.82 DIA
E
1.965 DIA
2.040 DIA
49.91 DIA
51.82 DIA
F
2.215 DIA
2.290 DIA
56.26 DIA
58.17 DIA
G
1.560 DIA
1.680 DIA
39.62 DIA
42.67 DIA
H
.965
1.085
24.51
27.56
L
.050
.145
1.27
3.68
M
---
1.085
---
27.56
P
---
.375 DIA
---
9.53 DIA
R
---
.469 DIA
---
11.91 DIA
S
3.200
3.300
81.28
83.82
T
---
.25
---
6.35
U
---
.50
---
12.70
V
---
.25
---
6.35
90° TYP
90° TYP
W
45° NOM
45° NOM
X
Y
.188 DIA THRU-4 HOLES 4.78 DIA THRU-4 HOLES
ON A 2.75 DIA B.C.
ON A 69.85 DIA B.C.
NOTES:
1. Do not use metal clamps on ceramic envelope.
2. Reservoir and cathode-heater have one side tied to cathode. Pinch-off assembly is electrically connected to
cathode.
3. This part may be metal disc with ceramic back up ring or a ceramic disc. When a metal disc is used,
connections are made to ceramic metal feed-throughs.
FIGURE 1. Outline drawing of electron tube type 7620 - Continued.
