INCH-POUND
MIL-PRF-1/1308E
27 July 2010
__
SUPERSEDING
MIL-PRF-1/1308D
19 July 1999
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, RECEIVING
TYPE 6360
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION: Double tetrode, rf amplifier, F1 = 200 MHz.
Outline:
6-4 (EIA).
Base:
E9-1.
Envelope: T6-1/2.
Cathode: Coated unipotential.
Base connections:
Pin No.
1
2
3
4
5
6
7
8
9
Element
1g1
k,
2g1
h
h
1a
1g2,
2a
hct
int sd
2g2
ABSOLUTE MAXIMUM RATINGS:
Parameter:
Ef
Eb
Ec1
Ec2
Ehk
Ik
Ib
Unit:
V
V dc
V dc
V dc
v
mA dc
mA dc
Maximum:
Class C, Telep
6.9 or 13.9
240
-150
200
100
2 x 40
2 x 37.5
(continuous duty)
Class C, Teleg
6.9 or 13.9
300
-150
200
100
2 x 50
2 x 45
(continuous duty)
Minimum:
5.7 or 11.3
---
---
---
---
---
---
Test conditions:
6.3 or 12.6
200
Adj
200
---
---
2 x 30
ABSOLUTE MAXIMUM RATINGS:
Parameter:
Ic1
Pg1
Pg2
Pp
Pi
TE
Alt
°C
Unit:
mA dc
W
W
W
W
ft
Maximum:
Class C, Telep
2x3
2 x 0.2
2 x 0.65 2 x 3.3
2 x 7.5
225
1/
(continuous duty)
Class C, Teleg
2x3
2 x 0.2
2 x 1.0
2 x 5.0 2 x 11.25
225
1/
(continuous duty)
Minimum:
---
---
---
---
---
---
---
Test conditions:
---
---
---
---
---
---
---
See footnotes at end of table I.
____________________________________________________________________________________________
GENERAL:
Qualification: Not required.
AMSC N/A
FSC 5960
