INCH-POUND
MIL-PRF-1/1071D
14 July 2009
_
SUPERSEDING
MIL-PRF-1/1071C(CR)
25 June 1999
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, GAS SWITCHING
TYPE 6962
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION: ATR, L-band, Fo = 1,285 MHz.
ABSOLUTE RATINGS:
Parameter:
Incident power
Du
Alt
Unit:
Mw
---
ft
Maximum:
2
0.001
10,000
Minimum:
---
---
---
PHYSICAL CHARACTERISTICS:
Dimensions:
See figures 1 and 2.
See figure 1 and 1/.
Mounting:
Weight:
6 pounds (approximate).
TEST CONDITIONS:
Parameter:
Incident power
tp
Du
VSWR
F
s
'
Unit:
kw
---
MHz
Test condition 1:
Maximum
525
4.4
0.001
1.05
1,298
Minimum
475
3.6
---
---
1,272
Test condition 2:
Maximum
2,100
4.4
0.001
---
1,298
Minimum
1,900
3.6
---
---
1,272
See footnotes at end of table I.
GENERAL:
Preproduction sample approval: Required. 2/
AMSC N/A
FSC 5960
