INCH-POUND
MIL-PRF-1/1069G
6 June 2006
SUPERSEDING
MIL-E-1/1069F
19 February 1981
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, RECEIVING
TYPE 5702WB
Inactive for new design
after 18 June 2001.
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
The requirements for acquiring the product described
herein shall consist of this document and MIL-PRF-1.
DESCRIPTION: Pentode, subminiature, sharp cutoff.
Outline
--- 3-6 (EIA).
Base
--- Pinch press (7 leads).
Envelope
--- T3.
Cathode
--- Coated unipotential.
Base connections:
Pin No.
--- 1
2
3
4
5
6
7
Element
--- a
g2
h
h
g3
k
g1
ABSOLUTE-MAXIMUM RATINGS:
Parameter:
Ef
Eb
Ec1 Ec2 Ec3 Ehk
Rk
Rg1
Ik
Pp
Pg2
TE
Alt
Ohms MegΩ mA dc
°C
Unit:
V
V dc V dc V dc V dc
v
W
W
ft
Maximum:
6.9
165
---
155
0
200
---
1.2
16.5
1.3
0.5
220
(see note 4)
Minimum:
5.7
---
-55
---
---
---
---
---
---
---
---
---
---
Test conditions:
6.3
120
0
120
0
0
200
0
---
---
---
---
---
___________________________________________________________________________________________
GENERAL:
Qualification : Not required.
Reliable tube.
AMSC N/A
FSC 5960
