MIL-PRF-1/1055F
Dimensions
Ltr
Notes
Inches
Millimeters
Min
Max
Min
Max
Conformance inspection, part 2
A
---
.250
---
6.35
B
.810
.818
20.57
20.77
C
1.219 1.281
30.96
32.53
D
.953
.984
24.21
24.99
E
.750
.813
19.05
20.65
F
.070
.078
1.78
1.98
4, 5
G
---
1.016
---
25.80
J
.539
.549
13.69
13.94
6
K
.318
.328
8.08
8.33
L
.180
.190
4.57
4.82
M
.365
.371
9.27
9.42
AE
.429
---
10.90
---
4
Conformance inspection, part 3
3
(periodic check)
N
---
.453
---
11.50
P
.560
.570
14.22
14.47
O
---
.609
---
15.46
R
.077
.097
1.96
2.46
S
---
.266
---
6.75
T
.015
.090
0.38
2.28
W
---
.285
---
7.24
1
X
---
.375
---
9.52
7
Z
.490
.520
12.45
13.20
Reference dimensions
U
.094
2.39
4, 5
V
.094
2.39
4, 5
Y
.016 R
0.41 R
AA
.750
19.50
2
AB
.547
13.89
2
AC
1.000
25.40
2
AD
1.109
28.17
2
AF
.453
11.51
4
FIGURE 1. Outline drawing of electron tube type 6442 - Continued.
9
