INCH-POUND
MIL-E-1/197F
17 September 2013
SUPERSEDING
MIL-E-1/197E
14 April 2003
MILITARY SPECIFICATION SHEET
ELECTRON TUBE, RECEIVING
TYPE 6L6WGB
Inactive for new design
after 7 March 1997.
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described
herein shall consist of this document and MIL-PRF-1.
DESCRIPTION:
Pentode, rugged, beam-power amplifier.
Outline
---
11-2 (EIA) except for base
Base
---
B7-59 or B6-84 (phenolic)
Envelope
---
T11
Cathode
---
Coated unipotential
Base connections:
Pin no.
---
1
2
3
4
5
7
8
k,
Element
---
nc
h
a
g2
g1
h
beam plates
ABSOLUTE RATINGS:
Parameter:
Ef
Eb
Ec1
Ec2
Ehk
Pp
Pg2
Alt
Unit:
V
V dc
V dc
V dc
v
W
W
ft
Maximum:
6.9
400
---
300
200
26
3.5
1/
Minimum:
5.7
---
---
---
---
---
---
---
Test conditions:
6.3
250
-14
250
---
---
---
---
GENERAL:
Qualification Not required.
First article test is required and shall consist of all tests in table I with a sample size of 2 for a lot size less than
or equal to 150 units and a sample size of 4 for a lot size greater than or equal to 151 units. All samples shall pass
conformance inspection part 1 of table I before continuing. Half of the samples shall then be subjected to
conformance inspection part 2, and the remaining samples shall be subjected to part 3, with no test failures permitted
during any testing.
After first article approval, acceptance testing shall consist of conformance inspection part 1 of table I with
sample size in accordance with table III, category XVI (acceptance level 10.0) of MIL-PRF-1.
AMSC N/A
FSC 5960
