MIL-DTL-24251/4D
REQUIREMENTS:
The retainer (base), adapter, and other parts, as shown in figure 1, shall be designed to meet the requirements of
MIL-DTL-24251, and to fit the shield and tube socket specified in table I.
Dimensions and configuration:
See figure 1 and table I.
Retainer (base):
Material-Brass, sheet, .032 inch (0.81 mm) thick, ASTM-B36/36M and ASTM-B121/B121M, composition 2,
annealed or aluminum alloy ASTM-B85/B85M, ASTM-B26/B26M, ASTM-B108/B108M; and SAE-J452, SAE-
AMS4290 and SAE-AMS4291.
Finish-Black cadmium plate, SAE-AMS-QQ-P-416, class 1, type II, optional finish: Henderlube or equal, chromate
MIL-DTL-5541.
Adapter:
Material-Brass, sheet, .015 inch (0.38 mm) thick on -3 and .025 inch (0.64 mm) thick on -4, ASTM-B36/B36M and
ASTM-B121/B121M, composition 2, annealed.
Finish-Black cadmium plate, SAE-AMS-QQ-P-416, class 3, type II, optional finish, Henderlube or equal.
The Part or Identifying Number (PIN) consists of the basic number of this specification sheet, preceded by the letter
"M", and a dash number taken from table I.
Example:
M24251/4-1
Basic document
Dash number
number
from table
3
