INCH-POUND
MIL-DTL-24251/3D
11 July 2013
SUPERSEDING
MIL-DTL-24251/3C
15 February 2008
DETAIL SPECIFICATION SHEET
SHIELD, ELECTRON TUBE, HEAT DISSIPATING
7 AND 9 PIN, MINIATURE
(SPLIT SHELL)
This specification sheet is inactive for
new design after 11 July 2013.
The requirements for acquiring the product described herein
shall consist of this specification sheet and MIL-DTL-24251.
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
NOTES:
1. All dimensions are in inches.
2. Millimeters are in parentheses.
3. Metric equivalents (to the nearest 0.01 mm) are given for general information only and are based upon
1 inch = 25.4 mm.
4. Unless otherwise specified, tolerance is 2 places ± .010 (0.25 mm); 3 places ± .005 (0.13 mm).
FIGURE 1. Dimensions and configuration.
AMSC N/A
FSC 5960
